Descrizione

• Maximum output level – 25 load 775mW, 32 load 685mW, 50 load 530mW, 100 load 320mW, 600 load 60mW
• Open circuit voltage 6v
• Input impedance 20K, Gain 28dB
• Frequency response 12Hz to 37kHz
• THD typically 0.003%
• Signal to noise ratio referenced to max output level -100dB (22Hz – 22kHz)
• Maximum Power requirements – 24VAC at 225mA (685mW 32)
• Dimensions: W 178mm x D 155mm x H 45mm.
