Descrizione
- Digital to analogue convertersDual Wolfson WM8740 24-bit DACs
- Digital filterAnalog Devices ADSP21261 DSP; upsampling to 24-bit/384kHz
- Analogue filter2-Pole Dual Differential Bessel Double Virtual Earth Balanced
- Frequency response20Hz to 20kHz (±0.1dB)*
- THD @ 1Khz 0dBFs<0.001% 24-bit
- THD @ 1kHz -10dBFs<0.001%
- THD @ 20kHz 0dBFs<0.002%
- Signal to Noise Ratio-112dBr
- Total correlated jitter<130pS
- Crosstalk @ 1kHz< -130dB
- Crosstalk @ 20kHz< -112dB
- Output impedance<50 Ohms
- Max. output level (unbalanced)2.1V rms
- Max. output level (balanced)4.2V rms (2.1V per phase)
- Digital input word widths supported16-24bit
- Digital input sampling frequencies supported32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz**, 192kHz
- Audio output upsamplingFixed 24-bit/384kHz
- Max power consumption12W
- ColourBlack or silver
- Dimensions (HxWxD)52 x 215 x 191mm; (2.0 x 8.6 x 7.6”)
- Weight1.2kg/2.6lbs
- *Steep filter disabled
- **Digital 1 & 2 Inputs only
- Headphone output
- THDat 1kHz 0dBFS 24-bit signal with 22kHz low pass filter = 0.001%
at 20khz 0dBFS 24-bit signal with 80kHz low pass filter = 0.003% - S/N-111dBrA
- Frequency response10Hz – 100kHz
- Recommend headphone impedance 32 Ohm to 600 Ohm.
